BRICK Semi Recessed
With its high performance as well as functionality in different project areas, BRICK has an aesthetic design with its semi-recessed, square form and minimalist body. It captures clear light output thanks to its deeply positioned LED light source.
-
Product Description
-
Technicial Specifications
-
Download Center
-
Datasheets
With its high performance as well as functionality in different project areas, BRICK has an aesthetic design with its semi-recessed, square form and minimalist body. It captures clear light output thanks to its deeply positioned LED light source.
| Housing | Aluminium Housing |
| Optical | Reflector |
| Optical Angles | 24° / 36° |
| IP Protection Class | IP20 |
| IK Impact Resistance Class | IK03 |
| Input Voltage | 220-240V AC 50/60 Hz |
| Consumption Power | 6 W / 8 W / 10 W /12 W |
| Source of Light | COB LED |
| Color Temperature | 2700K / 3000K / 4000K / 6500K |
| CRI | >80 / >90 |
| Working Ambient Temperature | -5 °C / +35 °C |
| Body Colors | RAL 9005 / RAL 9006 / RAL 9016 |
| Mounting Type | Recessed Mounted |
